Automatic Polarimeter

Automatic Polarimeter
Automatic Polarimeter
Product Code : 01
Brand Name : ADVANCE
Product Description

Our enterprise is actively engaged in presenting a premium quality Automatic Polarimeter. This polarimeter is used in the food industry for measurement of purity and concentration in carbohydrates, starches, lactose etc. in the chemical industry for the characterization of various chemicals. Our offered polarimeter is manufactured using optimum quality components as per the need of the clients. Furthermore, clients from across the globe can avail this Automatic Polarimeter within the promised time frame.

ADVANCE Digital Polarimeter combines the latest in Optoelectronic Technology with over Forty Five year of experience in Precision Analytical Instruments to introduce for the first time in India, a locally manufactured, affordable, low cost fully Automatic Digital Polarimeter The Polarimeter Model SucroPol & POL:PS has all the features required for regular Quality Control, Quality Assurance and Process Control as well as for Research applications.

The instrument finds application in the Pharmaceutical Industry, for measurement of Optical Rotation and Specific Rotation of amino Acids, Amino Sugars, Analgesics, Antibiotics, Steroids, Vitamins and other Pharmaceutical preparations and also for Pharmacological research of Ayurvedic Medicines.

Another proven application is in Sugar Mills where it is used round the clock, continuously, for measurement of Pol reading. It is useful to monitor the process and plant efficiency at each step of extraction and checks any unknown or unaccounted losses.

In Foodstuffs it is used for measurement of Purity and Concentration in Carbohydrates, Starches, Lactose, and Glucose etc. It finds wide application in Essential Oils and Fragrance industry for inspection of Raw Materials like Sandalwood Oil, Menthol, Eucalyptus Oil, Lemon, Rose Wood Oil, fragrances etc.

In the Chemical Industry it is used in identification and characterization of various Chemicals, Bi-polymers, and Natural Polymers etc. In Agricultural Sector the analysis of Agricultural Antibiotics, Hormones, Microbial Agro-Pharmaceuticals and Agricultural Products can be carried out using Automatic Polarimeters.

Key Features:

  • Fully Automatic Readout of
    • Optical Rotation
    • Specific Rotation
    • Concentration
    • International Sugar Scale

  • Large Multifunctional LCD Display
  • Easy Interactive Setup Menu
  • RS-232/USB Output Port
  • Automatic Calculation of Average Valueand Repeatability Factor
  • Additional Dust Protection Filters
  • Easy to use, does not require skilled chemist
  • Totally Eliminates Chances of all Pre-Judex Readings
  • RS232/USB Port For Computer Interface
  • Affordable Price, Readily available Cheaper Spare parts

Technical Details

Specification

Sucropol(T)

SucroPol

POL:PS

Angular Scale

± 89o

± 89o

±45o

Least Count (Angular Scale)

0.001o

0.01o

0.001o

Repeatability (Angular Scale)

± 0.001o

± 0.03o

± 0.035o

International Sugar Scale

±130o Z

±130o Z

±120Z o

Repeatability (ISS)

± 0.05o Z

± 0.1o Z

± 0.1o Z

Minimum Transmission

01% (can measure dark samples)

01% (can measure dark samples)

10.00%

Light Source

High Intensity Integrated LED with Imported Filter

High Intensity Integrated LED with Filter

Sodium Lamp

Display

9.7’’ Touch Screen

Touch Screen

Large Multifunctional LCD Display

Temperature Range

10-100oC

10--35oC

10--35oC

Cover/Panel Construction

ABS Body

ABS Body

MS Powder Coated

Peltier Cooling

Available

Not Available

Not Available

Prism

Glan Thompson

Glan Thompson

Glan Thompson

Temperature Control Accuracy

+0.1oC

1oC

1oC

Response Time

5°/sec

3°/sec

2°/sec

Connectivity

USB*4keyboard and mouse, printer; second display with VGA, Ethernet to internet, wireless network access by optical WLAN card

USB

RS232 Port

Wave length

589.44nm

589.44nm

589.44nm
